Topcon TRK-2P User Manual

65
OPTIONAL OPERATIONS
4 When the pupil is displayed tap the pupil. The measuring head moves to the position the pupil
image and alignment dot are at the center of the screen.
5 Using the button (L), move the left positioning bar to the left end of the
iris from the control panel side.
6 Using the button (R), move the right positioning bar to the right end of
the iris from the control panel side.
7 Tap the button.
NOTE
It is possible to move the positioning bar by tapping the positioning bar R/L
balance display.
R:0.00R:0.00 L:0.00L:0.00 R:0.00R:0.00 L:0.00L:0.00
Positioning bar control
R:0.00R:0.00 L:0.00L:0.00
Positioning bar control
R:0.00
R:0.00
L:0.00
L:0.00
Measurement
