Toro 31900A - Installing the Tie-Down Bracket; Installing the Seat; Installing the Steering Wheel

6
Installing the T ie-Down
Bracket
Models 31900A, 31901A, and
31907A Only
Parts needed for this procedure:
1 T ie-down bracket
2
Bolt (3/8 x 3-1/4 inches)
2
Nut (3/8 inch)
Procedure
Use 2 bolts (3/8 x 3-1/4 inches) and 2 nuts (3/8 inch)
to secure the tie-down bracket to the platform ( Figure
12 ).
g299562
Figure 12
1. T ie-down bracket 3. Nut
2. Bolt
7
Installing the Seat
Models 31900A, 31901A, and
31907A Only
Parts needed for this procedure:
1
Seat Kit (ordered separately; refer to your authorized
T oro distributor)
Procedure
Install the seat; refer to the Seat Kit Installation
Instructions .
8
Installing the Steering
Wheel
Models 31900A, 31901A, and
31907A Only
Parts needed for this procedure:
1
Steering wheel
1
Cover
Procedure
1. Remove the steering wheel from the shipping
skid ( Figure 13 ).
16
