g032951
Figure 88
1. Latch-mount assembly
3. Screen cover
2. Condenser lter
Replacing the Dome Light
Note: Refer to the Parts Catalog for the appropriate
bulb part number .
1. Use a screwdriver to remove the light lens from
the control panel. ( Figure 89 ).
g253616
Figure 89
1. Screwdriver
3. Lens
2. Bulb
2. Remove the bulb from the light base ( Figure 89 ).
3. Install a new bulb into the light base.
4. Install the lens into the control panel.
Filling the
W indshield-W iper-Fluid
Reservoir
Note: The windshield-wiper-uid reservoir is located
next to the engine on the right side of the machine.
1. Remove the cap ( Figure 90 ) on the reservoir .
g353836
Figure 90
1. Reservoir cap 2. Reservoir
2. Fill the reservoir with wiper uid.
3. Replace the cap on the reservoir .
73
