Cab Maintenance
Cleaning the Cab
Important: Use care around the cab seals ( Figure
86 ). If you are using a pressure washer , keep the
washer wand at least 0.6 m (2 ft) away from the
machine. Do not use the pressure washer directly
on the cab seals or under the rear overhang.
g034330
Figure 86
1. Seal
3. Do not pressure wash
under the rear overhang.
2. Keep wand 0.6 m (2 ft)
away .
Cleaning the Cab Air Filters
Service Interval : Every 400 hours
1. Remove the knobs and grates from the cab rear
overhang ( Figure 87 ).
g251432
Figure 87
1. Filter
3. Grate
2. Knob
2. Remove the air lters from the cab.
3. Clean the lters by blowing clean, oil-free,
compressed air through them.
Important: If either lter has a hole, tear , or
other damage, replace the lter .
4. Use the knobs and grates to install the lters
into the cab ( Figure 87 ).
Cleaning the
Cab-Condenser Filter
The purpose of the cab-condenser lter is to prevent
large debris, such as grass and leaves, from entering
the cab condenser and condenser fans.
1. Pull the screen cover straight down.
2. Clean the condenser lter with water .
Note: Do not use a pressure washer .
Important: If the lter has a hole, tear , or
other damage, replace the lter .
3. Allow the lter to dry before installing it into the
machine.
4. Rotate the lter screen around the tabs until
the latch locks into the latch-mount assembly
( Figure 88 ).
