the recommended pressure setting for the
attachment.
• Rotate the adjusting screw clockwise to
increase the pressure.
• Rotate the adjusting screw counterclockwise
to decrease the pressure.
Attachment
W eight-T ransfer Pressure
Rotary cutting unit
1,724 kPa (250 psi)
Flail Mower (Model No.
02835)
1,379 kPa (200 psi)
Snowthrower 1,724 kPa (250 psi)
Snow Blade (Model Number
MSC23345)
1,379 kPa (200 psi)
Rotary Broom (1.5 m or 5 ft) 1,724 kPa (250 psi)
9. Shut of f the engine and remove the key .
10. T ighten the jam nut at the end of the
weight-transfer spool, and torque the nut to 13
to 16 N∙m (10 to 12 ft-lb).
1 1. Install the cap on the test port.
12. Remove the pressure gauge from the test port.
Product Overview
g219621
Figure 24
1. Cutting unit
7. Roll bar
2. T raction pedal
8. Hood/engine compartment
3. Hydraulic-uid tank
9. Battery
4. Steering wheel
10. Fuel tank
5. Console
1 1. Parking brake
6. Operator ’ s seat 12. PT O shaft
