Toro 31900A - Raising the Hood

1. Chock the 2 rear wheels with chocks to prevent
the machine from moving.
2. Position the jack securely under the desired
jacking point.
3. After raising the front of the machine, use an
appropriate jack stand under the machine frame
to support the machine.
Raising the Rear of the Machine
Important: Ensure that no cables or hydraulic
components are between the jack and the frame.
g299730
Figure 45
1. Rear of the machine
3. Rear jack stand
point—frame tube
2. Rear jacking point—frame
tube
1. Chock the 2 front wheels with chocks to prevent
the machine from moving.
2. Position the jack securely under the desired
jacking point.
Important: 4-wheel-drive machines have
hydraulic lines that run close to the frame.
Ensure that your jack is positioned so that
the hydraulic lines are not damaged while
the machine is raised.
3. After raising the front of the machine, use an
appropriate jack stand under the machine frame
to support the machine.
Raising the Hood
1. Release the straps from each side of the
machine ( Figure 46 ).
g285428
Figure 46
2. Raise the hood ( Figure 46 ).
Note: If your machine is equipped with a hood lock,
use a key to unlock and raise the hood.
