3.21 ONLY ONE TEST 3 Tests and Diagnostics
Subtest 04 Kill Switch
This subtest checks if the Wireless communication switch works properly.
If the test is started with the switch ON, following message appears in the
display.
Kill switch is set to a start position (OFF)
Slide the switch to OFF position. Then, following message appears in the
display.
KILL SWITCH ON !!
Slide the switch to ON position. Then, following message appears in the
display.
KILL SWITCH OFF !!
After Sliding the switch to OFF position, return to the ONLY ONE TEST
menu automatically.
Subtest 05 USB
NOTE: When executing this subtest, USB test module and USB cable must be
connected.
This subtest checks if USB port works properly.
The following menu appears in the display.
#################################################################
######## ONLY ONE TEST Menu (XXXXXXXXX) #######
#################################################################
* *
* 0 ............ Port 0 (Left side) *
* 1 ............ Port 1 (Back left) *
* 2 ............ Port 2 (Back right) *
* 3 ............ Port 3 (Right side) *
* 9 ............ EXIT *
* *
*****************************************************************
.... Press test number[0-3, 9] ?
Connect the USB test module and USB cable to the computer.
Input the port test number and press Enter.
3-52 [CONFIDENTIAL] QOSMIO G20 Maintenance Manual (960-511)
