Appendix B Board Layout
B.8
ODD relay board
B.8 ODD
relay
board
<Front layout>
(
a
)
<Back layout>
(
b
)
Figure B-8 ODD relay board layout
Table B-8
ODD relay board connectors
Mark Number
Name
(a)
CN9680
ODD I/F connector
(b)
CN1820
ODD relay FFC I/F conne
ctor
QOSMIO G
20 Mainte
nance Manual
(960-5
11)
[CONF
IDENTIAL]
B-11
