B.9
TV antenna board
Appendix B Board Layout
B.9
TV antenna board
<Front
layout>
<Back
layout>
(
a
)
(
b
)
Figure B-9 TV antenna board layout
Table B-9
TV antenna board connectors
Mark Number
Name
(a)
J9610
TV antenna cable jack
(b) CN9611
TV
antenna
coax
ial cable connector
B-12
[C
ONF
IDENTIAL
]
QOSMIO G20 Mai
ntenance
Manual (
960-5
11)
358
