1 Hardware Overview 1.1 Features
1-2 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
 Keyboard
An-easy-to-use 85(US)/86(UK)-key keyboard provides a numeric keypad overlay for
fast numeric data entry or for cursor and page control. The keyboard also includes
two keys that have special functions in Microsoft® Windows® XP. It supports
software that uses a 101- or 102-key enhanced keyboard.
 Display
LCD
Built-in 17.1-inch, WXGA+ (1,440 x 900 dots)/WUXGA (1,920 x 1,200 dots)
amorphous silicon TFT color display.
Interface
To external monitor via - RGB connector
- S-video OUT connector
- D-port OUT connector
- HDMI port OUT connector
To internal monitor via - S-video IN connector
- Monitor IN port
 Sound system
Harman/Kardon-made stereo speaker is equipped. An internal microphone, external
monaural microphone jack and two stereo headphone jacks (one stereo headphone
jack can be used also as S/PDIF connector) are also equipped.
 Battery
The RTC battery is equipped inside the computer.
The main battery is a detachable lithium ion battery (4,700mAh:Li-Ion, 6cell/
7,050mAh:Li-Ion, 9cell).
 TV-tuner (Type III-A slot)
This enables to watch TV and record it. (Supporting world wide signal : NTSC, PAL
and SECAM).
 Wireless LAN (Mini card)
The wireless LAN is equipped on the Mini card.
 LAN/MODEM
Connectors for LAN and Modem are separately mounted.
