3.17 Expansion Test 3 Tests and Diagnostics
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 3-39
3.17 Expansion Test
To execute the expansion test, select 11 from the DIAGNOSTICS TEST MENU, press
Enter and follow the directions on the screen.
Subtest 01 PCMCIA wraparound
CAUTION: PCMCIA wraparound test is not supported for this model.
NOTE: To execute this subtest, the PC card wraparound connector is required.
This subtest checks the following signal line of the PC card slot:
 Address line
 REG#, CE#1, CE#2 line
 Data line
 Speaker line
 Wait line
 BSY#, BVD1 line
This subtest is executed in the following order:
Sub# Address Good Bad Contents
01 00001
00001
nn
nn
xx
xx
Address line
REG#, CE#1, CE#2
nn=A0, 90, 80, 00
02 00002 ww rr Data line
ww=write data, rr=read
data
03 00003 –– –– Speaker line
04 00004 40,80 xx Wait line (40<xx<80)
05 00005 nn xx Other lines (BSY#, BVD1)
NN=21, 00
NOTE: Select the subtest number01, The following message will appear:
Test slot number select (1:slot0, 2:slot1, 0:slot0&1)?
