4 Replacement Procedures 4.7 Keyboard
4.7 Keyboard
Removing the keyboard
The following describes the procedure for removing the keyboard (See Figure 4-10 and 4-11).
CAUTION: As the keytop may fall out, when handling the keyboard always hold it by the
frame and do not touch the keytop.
1. Insert your finger into the slot between the keyboard holder and computer. Then, lift
up the keyboard holder while unlatching.
2. Remove the following screw.
• M2.5×4B FLAT BIND screw ×2
Keyboard holder
M2.5x4B FLAT BIND
M2.5x4B FLAT BIND
Figure 4-10 Removing the keyboard (1)
4-20 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
