4.6 Speaker cover 4 Replacement Procedures
4.6 Speaker cover
Removing the Speaker cover
The following describes the procedure for removing the speaker cover (See Figure 4-9).
1. Turn the computer face up and open the display.
2. Turn the speaker cover counterclockwise and take it out from the slot.
Speaker cover
Figure 4-9 Removing the speaker cover
Installing the Speaker cover
The following describes the procedure for installing the speaker cover (See Figure 4-9).
1. Install the speaker cover to the slot and turn it clockwise.
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 4-19
