4 Replacement Procedures 4.3 ExpressCard & PC card / Bridge media
4.3.2 Bridge media (SD Card/ Memory Stick/ xDPicture Card/ MultiMedia card)
Removing the Bridge media
The following describes the procedure for removing the Bridge media (See Figure 4-3).
CAUTION: Insert or remove a Bridge Media in accordance with any instructions in the
each Bridge Media manual or the manuals of the computer system you are
using.
1. Push the Bridge media. It will pop out partly when you release, so pull out the card.
(For an instance, SD card is described in the figure 4-3.)
Bridge media
(SD card)
Figure 4-3 Removing the Bridge media
Installing the Bridge media
The following describes the procedure for installing the Bridge media (See Figure 4-3).
1. Insert the Bridge media and press it until it is securely connected.
4-12 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
