Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-27
C.35 CN9990 RTC battery connector (3-pin)
Table C-35 RTC battery connector (3-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 (R3V) I 2 NC -
3 GND -
C.36 CN8771 CPU FAN connector (4-pin)
Table C-36 CPU FAN connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 P5V - 2 FANGO-P3P O
3 GND - 4 (FPWMO-S3P) O
C.37 CN8781 VGA FAN connector (4-pin)
Table C-37 VGA FAN connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 P5V - 2 FANG1-P3P O
3 GND - 4 (FPWMO-S3P) O
C.38 CN9600 MCE module connector (12-pin)
Table C-38 MCE module connector (12-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 ZUSBIR-E3P I/O 2 ZUSBIR-E3N I/O
3 LERNON-P5N O 4 LERNRX-P5N I
5 MCE-E3V - 6 IRBLS2-P5P O
7 IRBLS1-P5P O 8 RCIRRX-E5P I
9 GND - 10 ZUSBBL-E3P I/O
11 ZUSBBL-E3N I/O 12 MCE-E5V -
1T GND - 2T GND -
