Appendix C Pin Assignments Appendices

QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-21

C.19 CN4610 USB I/F connector Port2/Port4 (8-pin)

Table C-19 USB I/F connector Port2/Port4 (8-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 USB01PS-E5V -

2 ZUSBP4-E3N I/O

A3 ZUSBP4-E3P I/O A4 GND -

B1 USB0PS-E5V - B2 ZUSBP2-E3N I/O

B3 ZUSBP2-E3P I/O B4 GND -

1T GND - 2T GND -

3T GND - 4T GND -

5T GND - 6T GND -

C.20 CN4611 USB I/F connector Port6/Port7 (8-pin)

Table C-20 USB I/F connector Port6/Port7 (8-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 USB1PS-E5V - 2 ZUSBP7-E3N I/O

3 ZUSBP7-E3P I/O 4 GND -

5 USB1PS-E5V - 6 ZUSBP6-E3N I/O

7 ZUSBP6-E3P I/O 8 GND -

1T GND - 2T GND -
