Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-15
C.9 CN2430 ISDB-t Tuner I/F connector (124-pin)
Table C-9 ISDB-t Tuner I/F connector (124-pin) (1/2)
PIN No. Signal name I/O PIN No. Signal name I/O
1 T2
-P5V - 2 T2
-P5V -
3 T2A-P5V - 4 T2A-P5V -
5 T2A-P5V - 6 T2A-P5V -
7 NC - 8 NC -
9 T2A-GND - 10 T2A-GND -
11 T2A-GND - 12 T2A-GND -
13 T2A-GND - 14 T2A-GND -
15 GND - 16 NC -
17 NC 18 T2A-P5V I
19 T2-P3V - 20 PIRQD-P3N I/O
21 NC O 22 T31DSL-P3P I/O
23 GND - 24 NC -
25 X33TU2-P3P I 26 (PCIRS1-S3N) O
27 GND - 28 T2P3V I
29 PREQ3-P3N I 30 PGNT2-P3N O
31 T2-P3V I 32 GND -
33 AD31-P3P I/O 34 NC -
35 AD29-P3P I/O 36 NC -
37 GND - 38 AD30-P3P I/O
39 AD27-P3P I/O 40 T-P3V I
41 AD25-P3P I/O 42 AD28-P3P I/O
43 PREQ1-P3N I 44 AD26-P3P I/O
45 CBE3-P3N I/O 46 AD24-P3P I/O
47 AD23-P3P I/O 48 T1IDSL-P3P I/O
49 GND - 50 GND -
51 AD21-P3P I/O 52 AD22-P3P I/O
53 AD19-P3P I/O 54 AD20-P3P I/O
55 GND - 56 PAR-P3P I/O
57 AD17-P3P I/O 58 AD18-P3P I/O
59 CBE2-P3N I/O 60 AD16-P3P I/O
61 IRDY-P3N I/O 62 GND -
63 T2-P3V I 64 FRAME-P3N I/O
65 CLKRUN-P3N I/O 66 TRDY-P3N I/O
67 SERR-P3N I 68 STOP-P3N I/O
