Appendix C Pin Assignments Appendices

QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-17

C.10 CN2450 BC board I/F connector (8-pin)

Table C-10 BC board I/F connector (8-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 BCAS-P5V - 2 BCIO-P5P I/O

3 BCRST-P3N I 4 GND -

5 XBCCLK-P3P O 6 GND -

7 BCCDET-P3N O 8 GND -

1T GND - 2T GND -

C.11 CN2600 PCI-Express mini card I/F connector (52-pin)

Table C-11 PCI-Express mini card I/F connector (52-pin) (1/2)

PIN No. Signal name I/O PIN No. Signal name I/O

1 PEWAKE-E3N O 2 P3V -

3 WCHDAT-P3P O 4 GND -

5 WCHCLK-P3P O 6 1R5-P1V -

7 MPEXRQ-P3N I 8 NC -

9 GND - 10 NC -

11 XPEMPE-P3N O 12 NC -

13 XPEMPE-P3P O 14 NC -

15 GND - 16 NC -

17 NC - 18 GND -

19 NC - 20 (WLON-S3N) O

21 GND - 22 PLTRS2-E3N -

23 ZPERWL-P1N I 24 E3V -

25 ZPERWL-P1P I 26 GND -

27 GND - 28 1R5-P1V -

29 GND - 30 SMBCL1-P3P O

31 ZPETWL-P1N O 32 SMBDAT-P3P O

33 ZPETWL-P1P O 34 GND -

35 GND - 36 NC -

37 NC - 38 1R5-P1V -

39 NC - 40 GND -

41 NC - 42 NC -

43 NC - 44 NC -

45 NC - 46 NC -

47 NC - 48 1R5-P1V -
