Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-31
C.46 CN9613 S-Video connector (4-pin)
Table C-46 S-Video connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 (GND) - 2 (GND) -
3 NLUMAIN-PXP I 4 CROMIN-PXP I
1T GND - 2T GND -
3T GND - 4T GND -
C.47 J9612 AV-in connector (5-pin)
Table C-47 AV-in connector (5-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 EXINR I 2 (TIF-GND) -
3 EXCVBS-PXP I 4 EXINL I
5 (TIF-GND) -
C.48 J9614 TV-in connector (12-pin)
Table C-48 TV-in connector (12-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND - 2 TIF-GD -
3 EXINR-PXP O 4 TVA-P3V -
5 EXINL-PXP O 6 TIF-GD -
7 EXCVBS-PXP O 8 TIF-GD -
9 CROMIN-PXP O 10 TIF-GD -
11 LUMAIN-PXP O 12 GND -
