Appendices Appendix C Pin Assignments
C-32 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
LE board (FCTLE*)
C.49 CN9510 System board I/F connector (20-pin)
Table C-49 System board I/F connector (20-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND - 2 RCIRRX-S5P O
3 BTLED-M5N I 4 LERNLE-S3P I
5 P5V - 6 LERNRX-P5N O
7 LERNON-P5N I 8 FMLED-P5N I
9 BTSWON-S3N I 10 GND -
11 ESTLRD-S5N I 12 SATLED-S5N I
13 BAT1GR-S5N I 14 BAT1OR-S5N I
15 M5V - 16 PWLEGR-S5N I
17 PWLEOR-S5N I 18 DCINGR-S5N I
19 DCINOR-S5N I 20 GND -
1T GND - 2T GND -
