Appendices Appendix C Pin Assignments
C-8 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
C.4 CN1850 1st HDD I/F connector (22-pin)
Table C-4 1st HDD I/F connector (22-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
S1 GND - S2 ZSATT0-P1P I
S3 ZSATT0-P1N I S4 GND -
S5 ZSATR0-P1N I S6 ZSATR0-P1P I
S7 GND -
P1 P3V I P2 P3V I
P3 P3V I P4 GND -
P5 GND - P6 GND -
P7 P5V I P8 P5V I
P9 P5V I P10 GND -
P11 GND - P12 GND -
P13 NC - P14 NC -
P15 NC -
C.5 CN1860 2nd HDD I/F connector (22-pin)
Table C-5 2nd HDD I/F connector (22-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
S1 GND - S2 ZSATT2-P1P I
S3 ZSATT2-P1N I S4 GND -
S5 ZSATR2-P1N I S6 ZSATR2-P1P I
S7 GND -
P1 P3V I P2 P3V I
P3 P3V I P4 GND -
P5 GND - P6 GND -
P7 P5V I P8 P5V I
P9 P5V I P10 GND -
P11 GND - P12 GND -
P13 NC - P14 NC -
P15 NC -
