Appendices Appendix C Pin Assignments
C-34 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
SW board (FCTSW*)
C.52 CN9660 System board I/F connector (20-pin)
Table C-52 System board I/F connector (20-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 LED I 2 LED O
3 NC - 4 PWRSW-S3N O
5 TVBTN-S3N O 6 CDBTN-S3N O
7 KBRT3-S3N O 8 KBRT2-S3N O
9 KBRT1-S3N O 10 KBRT0-S3N O
11 NC - 12 KBSC16-S3N I
13 GND - 14 IPDCLK-P5P I/O
15 GNBTNA-S3N O 16 GNBTNB-S3N O
17 GNBTNC-S3N O 18 GNBTND-S3N O
19 GNBTNE-S3N O 20 PNLOFF-S3N O
1T GND - 2T GND -
