Appendices Appendix C Pin Assignments

C-18 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)

Table C-11 PCI-Express mini card I/F connector (52-pin) (2/2)

PIN No. Si

nal name I/O PIN No. Si

nal name I/O

49 NC - 50 GND -

51 NC - 52 P3V -

1T GND - 2T GND -

C.12 CN3010 MDC I/F connector (12-pin)

Table C-12 MDC I/F connector (12-pin)

PIN No. Signal name I/O PIN No. Signal name I/O

1 GND - 2 NC -

3 ACZOT1-P3P I/O 4 NC -

5 GND - 6 E3V -

7 ACZSY1-P3P O 8 GND -

9 ACZIN1-E3P I/O 10 GND -

11 ACZRS1-E3N O 12 XAZBC1-P3P O

1T GND - 2T GND -

3T GND - 4T GND -

5T GND - 6T GND -
