Toshiba Qosmio G30 - Display Latch Hook

4.33 Display latch hook 4 Replacement Procedures
4.33 Display latch hook
Removing the display latch hook
The following describes the procedure for removing the display latch hook (See Figure 4-49).
1. Remove the following screws securing the display latch hook.
• M2.5×6S Tapping screw ×2
2. Pull up and remove the display latch hook from the display rear cover.
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 4-77
M2.5x6S Tapping
Display latch hook
Figure 4-49 Removing the display latch hook
Installing the display latch hook
The following describes the procedure for installing the display latch hook (See Figure 4-49).
1. Install the display latch hook to the display rear cover and secure it with the
following screws.
• M2.5×6S Tapping screw ×2
