3 Tests and Diagnostics 3.3 Check of the RAID configuration
3.3.2 Check of the screen display
Contents of the screen displayed are shown below.
3.3.2.1 RAID-1
When the “RAID-1” is displayed in the shown below, it is judged that the RAID is
configured by two drives.
TOSHIBA RAID / RAID Information Display Rev xx.xx.xxxx
Copyright(c) 2005 TOSHIBA CORPORATION. All Rights Reserved.
Level Status Capacity
LD0 RAID-1 DEGRADE xxGB
Write cache : Enable
Degrade Bootup : Yes
MBR Protection : Disable
S.M.A.R.T : Enable
Port Assign Status Size Model Rev
0 LD0-0 ONLINE xxGB FUJITSU-------------- xxxxxxx
1 LD0-1 FAILED xxGB FUJITSU-------------- xxxxxxx
< RAID: not OPTIMAL >
3.3.2.2 RAID-0 (1)
When there is one LD and “RAID-0 OPTIMAL” is displayed in the shown below,
it is judged that the RAID is configured by two drives.
TOSHIBA RAID / RAID Information Display Rev xx.xx.xxxx
Copyright(c) 2005 TOSHIBA CORPORATION. All Rights Reserved.
Level Status Capacity
LD0 RAID-0 OPTIMAL xxGB
Write cache : Enable
Degrade Bootup : Yes
MBR Protection : Disable
S.M.A.R.T : Enable
Port Assign Status Size Model Rev
0 LD0-0 ONLINE xxGB xxxxxxx-------------- xxxxxxx
1 LD0-1 FAILED xxGB xxxxxxx-------------- xxxxxxx
< RAID: not OPTIMAL >
3-10 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
