Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-9
C.6 CN2110 PC card I/F connector (150-pin)
Table C-6 PC card I/F connector (150-pin) (1/3)
PIN No. Signal name I/O PIN No. Signal name I/O
1 GND - 2 GND -
3 ZUSBEX3-E3N I/O 4 ZUSBEX-E3P I/O
5 GND - 6 CPUSB-E3N O
7 N.C (Reserve) - 8 NC (Reserve) -
9 GND - 10 NC (Reserve) -
11 CRD-E3V I 12 CRD-E3V I
13 CRD1R5-P1V I 14 CRD1R5-P1V I
15 CRD1R5-P1V I 16 PEWAKE-S3N I
17 GND - 18 CRD-E3V I
19 CRD-E3V I 20 CRDRST-E3N -
21 CRD-P3V I 22 CRD-P3V I
23 CRD-P3V I 24 CRD-P3V I
25 GND - 26 CRDCRQ-E3N O
27 CPPE-E3N O 28 GND -
29 GND - 30 GND -
31 XPECRD-P3N I 32 XPECRD-P3P I
33 GND - 34 ZERCRD-P1N I
35 ZERCRD-P1P I 36 GND -
37 GND - 38 GND -
39 GND - 40 GND -
41 ZETCRD-P1N I 42 ZETCRD-P1P I
43 GND - 44 N.C -
45 N.C - 46 N.C -
47 N.C - 48 N.C -
49 N.C - 50 N.C -
51 GND - 52 N.C -
53 N.C - 54 N.C -
55 N.C - 56 N.C -
57 N.C - 58 N.C -
59 GND - 60 N.C -
61 N.C - 62 N.C -
63 N.C - 64 N.C -
65 N.C - 66 N.C -
67 GND - 68 N.C -
