Appendices Appendix C Pin Assignments
C-10 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Table C-6 PC card I/F connector (150-pin) (2/3)
PIN No. Signal name I/O PIN No. Signal name I/O
69 N.C - 70 N.C -
71 N.C - 72 N.C -
73 N.C - 74 GND -
75 GND - 76 GND -
77 GND - 78 ACCD1-P3N I/O
79 ACAD00-PYP I/O 80 ACAD02-PYP I/O
81 ACAD01-PYP I/O 82 ACAD04-PYP I/O
83 ACAD03-PYP I/O 84 GND -
85 ACAD06-PYP I/O 86 ACAD05-PYP I/O
87 ACD14-PYP I/O 88 ACAD07-PYP I/O
89 ACAD08-PYP I/O 90 ACCBE0-PYN I/O
91 ACAD10-PYP I/O 92 GND -
93 ACAD09-PYP I/O 94 ACVS1-P3P I/O
95 ACAD11-PYP I/O 96 ACAD13-PYP I/O
97 ACAD12-PYP I/O 98 ACAD15-PYP I/O
99 ACAD14-PYP I/O 100 GND -
101 ACAD16-PYP I/O 102 ACCBE1-PYN I/O
103 ACA18-PYP I/O 104 ACPAR-PYP I/O
105 ACLOCK-PYN I/O 106 ACPERR-PYN I/O
107 ACSTOP-PYN I/O 108 GND -
109 ACGNT-PYN - 110 ACDEVS-PYN I/O
111 ACINT-PYN I/O 112 MCVCCA-PYV I/O
113 MCVCCA-PYV I/O 114 MCVPPA-PYV I/O
115 ACCLK-PYP I/O 116 ACTRDY-PYN I/O
117 ACIRDY-PYN I/O 118 GND -
119 ACFRAM-PYN I/O 120 ACCBE2-PYN I/O
121 ACAD17-PYP I/O 122 ACAD18-PYP I/O
123 ACAD19-PYP I/O 124 ACAD20-PYP I/O
125 ACVS2-P3P I/O 126 GND -
127 ACAD21-PYP I/O 128 ACRST-PYN I/O
129 ACAD22-PYP I/O 130 ACSERR-PYN I/O
131 ACAD23-PYP I/O 132 ACREQ-PYN I/O
133 ACAD24-PYP I/O 134 GND -
