Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-11
Table C-6 PC card I/F connector (150-pin) (3/3)
PIN No. Signal name I/O PIN No. Signal name I/O
135 ACCBE3-PYN I/O 136 ACAD25-PYP I/O
137 ACAUDI-PYP I/O 138 ACAD26-PYP I
139 ACSTSC-PYP I/O 140 ACAD27-PYP I/O
141 ACAD28-PYP I/O 142 GND -
143 ACAD29-PYP I/O 144 ACAD30-PYP I/O
145 ACD02-PYP I/O 146 ACAD31-PYP I/O
147 ACCLKR-PYN I/O 148 ACCD2-P3N I/O
149 GND - 150 GND -
