Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-25
C.29 CN6170 Speaker connector (4-pin)
Table C-29 Speaker connector (4-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 SPOTL-PXN O 2 SPOTL-PXP O
3 SPOTR-PXP O 4 SPOTR-PXN O
C.30 J6310 Headphone connector (6-pin)
Table C-30 Headphone connector (6-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 A-GND - 2 HEADL1-PXP I
3 HEADR1-PXP I 4 (A4R7-P4V) -
5 A-GND - 6 NC -
C.31 DS6320 Headphone/SPDIF connector (9-pin)
Table C-31 Headphone/SPDIF connector (9-pin)
PIN No. Signal name I/O PIN No. Signal name I/O
1 (SPKEN-P4N)A I 2 HEADL2-PXP I
3 HEADR2-PXP I 4 A-GND -
5 SPDJIN-P3N I 6 NC -
7 DOUT-P3P O 8 SPD3V-P3V -
9 GND -
