Appendices Appendix C Pin Assignments

C-16 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)

Table C-9 ISDB-t Tuner I/F connector (124-pin) (2/2)

PIN No. Signal name I/O PIN No. Signal name I/O

69 GND - 70 T1-P3V I

71 PERR-P3N I/O 72 DEVSEL-P3N I/0

73 CBE1-P3N I/O 74 GND -

75 AD14-P3P I/O 76 AD15-P3P I/O

77 GND - 78 AD13-P3P I/O

79 AD12-P3P I/O 80 AD11-P3P I/O

81 AD10-P3P I/O 82 GND -

83 GND - 84 AD09-P3P I/O

85 AD08-P3P I/O 86 CBE0-P3N I/O

87 AD07-P3P I/O 88 T1-P3V -

89 T2-P3V I 90 AD06-P3P I/O

91 AD05-P3P I/O 92 AD04-P3P I/O

93 BCRST-P3N O 94 AD02-P3P I/O

95 AD03-P3P I/O 96 AD00-P3P I/O

97 P5V I 98 P5V -

99 AD01-P3P I/O 100 NC -

101 GND - 102 GND -

103 BCIO-P5P I/O 104 TMPTU1-SXP I

105 NC - 106 TMPMPG-SXP I

107 NC - 108 NC -

109 NC - 110 TMPTU3-SXP I

111 BCCDET-P3N I 112 (Aver EX_IN_R) -

113 GND - 114 GND -

115 XBCCLK-P3P O 116 GND -

117 GND - 118 GND -

119 GND - 120 GND -

121 BCPWON-P3P I 122 (TADCEN-P3P) -

123 P5V I 124 NC -

1T GND - 2T GND -
