Appendices Appendix C Pin Assignments
C-14 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Table C-8 WW Tuner I/F connector (124-pin) (2/2)
PIN No. Signal name I/O PIN No. Signal name I/O
69 GND - 70 T1-P3V I
71 PERR-P3N I/O 72 DEVSEL-P3N I/0
73 CBE1-P3N I/O 74 GND -
75 AD14-P3P I/O 76 AD15-P3P I/O
77 GND - 78 AD13-P3P I/O
79 AD12-P3P I/O 80 AD11-P3P I/O
81 AD10-P3P I/O 82 GND -
83 GND - 84 AD09-P3P I/O
85 AD08-P3P I/O 86 CBE0-P3N I/O
87 AD07-P3P I/O 88 T1-P3V -
89 T1-P3V I 90 AD06-P3P I/O
91 AD05-P3P I/O 92 AD04-P3P I/O
93 BCRST-P3N O 94 AD02-P3P I/O
95 AD03-P3P I/O 96 AD00-P3P I/O
97 P5V I 98 P5V -
99 AD01-P3P I/O 100 NC -
101 GND - 102 GND -
103 BCIO-P5P I/O 104 TMPTU1-SXP I
105 NC - 106 TMPMPG-SXP I
107 NC - 108 NC -
109 NC - 110 TMPTU3-SXP I
111 BCCDET-P3N I 112 (Aver EX_IN_R) -
113 GND - 114 GND -
115 XBCCLK-P3P O 116 GND -
117 GND - 118 GND -
119 GND - 120 GND -
121 BCPWON-P3P I 122 (TADCEN-P3P) -
123 P5V I 124 NC -
