Toshiba Qosmio G30 Maintenance Manual

4 Replacement Procedures 4.5 Memory module
3. Remove the memory module while opening the left and right latches.
Memory module
Latch
Latch
Figure 4-8 Removing the memory module
Installing the memory module
To install the memory module, confirm that the computer is in boot mode. Then perform the
following procedure (See Figure 4-7 and 4-8).
1. Insert the memory module into the connector of the computer slantwise and press it
to connect firmly.
CAUTION: Be sure to install a memory module to slot A (CN1400). The computer does
not boot when a memory module in installed into slot A.
After installing the memory module, confirm that the memory module is
secured with the left and right latches.
Never press hard or bend a memory module.
2. Install the memory slot cover and secure it with the screw (with e-ring).
3. When the power of the computer is turned on, the computer checks automatically the
memory size. Confirm that the new memory is detected correctly.
4. If the memory is not detected, check that it is connected correctly.
4-18 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
