3 Tests and Diagnostics 3.30 Sound Test program
3-92 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
3.30.3 CD Sound (Standard)
To execute the CD Sound (Standard) test, press 3 and Enter. Insert the test media
(TOSHIBA TEST CD-ROM or ABEX TEST CD-ROM) or music CD on the market (if the
test media can not be prepared). Following menu appears in the display.
For details on use of test media, refer to (1) Test media (Toshiba-made test media).
For details on use of audio CD on the market, refer to (2) Audio CD.
(1) Test media (Toshiba-made test media)
CD/DVD TEST IN PROGRESS XXXXXXXX
xxxxxxx DIAGNOSTIC TEST VX.XX
[Ctrl]+[Break] : test end
[Ctrl]+[C] : key stop
SUB-TEST : XX
PASS COUNT : XXXXX ERROR COUNT: XXXXX
WRITE DATA : XX READ DATA : XX
ADDRESS : XXXXXX STATUS : XXX
01 – Japanese Narration
02 – English Narration
03 – Test Tone A (100Hz – 20Hz)
04 - Test Tone B (400Hz – 3KHz L-R)
Drive # = 0, ATAPI status =00
Command = XX
[[Block address = XXXXXXXX]]
[[Block length = XXXXXXXX]]
Final : Block address = XXXXXXXXX
Subtest01 Japanese Narration
Selected this subtest, narration in Japanese starts and following message
appears in the display.
Play start CD sound !
Press any key <Play stop>.
Press any key and stop the narration. Then return to the CD Sound (Standard)
test menu.
