4 Replacement Procedures 4.31 LCD cable
4-74 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Installing the LCD cable
The following describes the procedure for installing the LCD cable (See Figure 4-47).
1. Arrange the LCD cable by putting it through the slot of cover assembly.
2. Install the LCD cable holder plate to the display rear cover and secure it with the
following screw.
• M2.5×6S Tapping screw ×1
3. Installing the hinge cap (L) while hooking the tabs.
CAUTION: When installing the hinge cap, do not mistake the left for the right and vice
versa. “L” for the left and “R” for the right are marked on the hinge cap.
To Next Page
