4.36 Fluorescent Lamp 4 Replacement Procedures
9. Secure both sides of LCD module with 6 screws.
CAUTION: Make sure that the bent portion of bezel (D) in the form of “]” is not on the
lib.
The torque tightening screws shall
be 0.1 N m.
Figure 4-76 Replacing 17.1 Inch Sharp fluorescent lamp (17)
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 4-105
