Appendices Appendix B Board Layout
B-2 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Table B-1 System board connectors (front)
Number Name
IS2101 Bridge media slot
CN2470 TV signal splitter
CN9550 JK board I/F connecter
CN9530 FS board I/F connector
CN9600 MCE I/F connector
CN9500 LE board I/F connecter
CN9650 SW board I/F connecter
CN2600 Wireless LAN card I/F connector
CN3490 Debugging port
CN3010 MDC I/F connecter
CN5000 LCD I/F connecter
CN2450 BC board I/F connecter
CN4400 Bluetooth FFC connector
CN3330 Volume sensor cable connector
CN5816 FL inverter connector
CN9990 RTC battery connector
CN6050 Internal microphone
CN3201 Touch pad FFC connector
CN3200 Keyboard I/F connector
