Appendices Appendix B Board Layout
B-4 [CONFIDENTIAL] QOSMIO G30 Maintenance Manual (960-546)
Table B-2 System board ICs and connectors (back)
Number Name
CN1400 Memory module (base) I/F connector
CN1410 Memory module (expansion) I/F connector
CN1850 HDD-1 I/F connector
CN5080 RGB I/F connector
CN5805 HDMI connector
CN5502 D-Video connector
CN5501 S-Video connector
J6310 Headphone connector
J6051 External microphone
DS6320 SPDIF connector
CN1810 ODD connector
CN2110 PC card I/F connector
CN4200 i.LINK (IEEE1394) port
CN8771 CPU fan cable connector
CN8781 VGA fan cable connector
CN8800 DC-IN connecter
CN8810 1
st
battery connecter
CN1860 HDD-2 I/F connecter
CN6480 1 Bit amp connector
IS1050 CPU
J4100 Network connecter
CN4611 USB connecter
CN6170 Speaker cable connector
CN4610 USB connector
IC5000 GPU
IC1200 MCH
IC1600 ICH7-M
IC2000 Card controller
