Appendix C Pin Assignments Appendices
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] C-3
Table C-1 Memory connector 0 (200-pin) (3/3)
PIN No. Signal name I/O PIN No. Signal name I/O
131 BDQS4-B1P I/O 132 GND -
133 GND - 134 BDQ38-B1P I/O
135 BDQ34-B1P I/O 136 BDQ39-B1P I/O
137 BDQ35-B1P I/O 138 GND -
139 GND - 140 BDQ44-B1P I/O
141 BDQ40-B1P I/O 142 BDQ45-B1P I/O
143 BDQ41-B1P I/O 144 GND -
145 GND - 146 BDQS5-B1N I/O
147 BMD5-B1P I 148 BDQS5-B1P I/O
149 GND - 150 GND -
151 BDQ43-B1P I/O 152 BDQ46-B1P I/O
153 BDQ42-B1P I/O 154 BDQ47-B1P I/O
155 GND - 156 GND -
157 BDQ48-B1P I/O 158 BDQ52-B1N I/O
159 BDQ54-B1P I/O 160 BDQ53-B1N I/O
161 GND - 162 GND -
163 N.C. - 164 MCK4-B1P I
165 GND - 166 MCK4-B1N I
167 BDQS6-B1N I/O 168 GND -
169 BDQS6-B1P I/O 170 BDM6-B1P I
171 GND - 172 GND -
173 BDQ51-B1P I/O 174 BDQ50-B1P I/O
175 BDQ55-B1P I/O 176 BDQ49-B1P I/O
177 GND - 178 GND -
179 BDQ57-B1P I/O 180 BDQ56-B1P I/O
181 BDQ60-B1P I/O 182 BDQ61-B1P I/O
183 GND - 184 GND -
185 BDM7-B1P I 186 BDQS7-B1N I/O
187 GND - 188 BDQS7-B1P I/O
189 BDQ58-B1P I/O 190 GND -
191 BDQ59-B1P I/O 192 BDQ62-B1P I/O
193 GND - 194 BDQ63-B1P I/O
195 SMBDAT-P3P I/O 196 GND -
197 SMBCLK-P3P I/O 198 GND -
199 P3V I 200 P3V I
