2.4 System Board Troubleshooting 2 Troubleshooting Procedures
QOSMIO G30 Maintenance Manual (960-546) [CONFIDENTIAL] 2-33
Table 2-5 Debug port (Suspend mode) error status (2/3)
LED Status Test item Contents
Storing of PIT
Starts sequence for storing display system
Storing of PIC
Storing of DMAC
Storing of system status command port
Storing of PCMCIA card
Storing of RTC
Storing of original HW for system
(F133h)
Calculation of check sum
(conventional memory)
Processing of VGA –off (boot)
Suspending of HDD (boot)
F137h
Transition to S5 of Bluetooth (boot) (For models supporting Bluetooth)
Suspending of boot / resume for PnP
(Stores PnP resource information into Flash
ROM)
F138h
Suspending of boot / resume for password (Stores password information into Flash ROM)
F139h
Waiting for completion of suspending for HDD
password
Prohibition of PCI arbiter
Setting of Wakeup event
Power-off of PC card
Re-setting backup current
Forced off of fan
Checks if off-process for resume is needed
Power LED control during suspending
Isolates built-in LAN
F13Ah
Makes the power of sound off
F13Bh
Model-unique processing just before
suspending
Waiting for completion of dividing for
suspending
Stops dividing of extension command for
power off
