Introduction Connections Basic Setup Playback
Editing
VCR Functions Others
Function Setup
Recording
99
EN
Specifications
Note
• The specifications and design of this product are subject to change without notice.
General
System HDD, DVD-Video, DVD-RW / R, VCD, CD-DA, CD-RW / R,
Video Cassette Tape
VCR video heads Four heads
HDD Internal 3.5 inch HDD 160 GB
Power requirements 220–240 V ± 10%, 50 Hz ± 0.5%
Power consumption 60 W (standby: 8.5 W)
Weight 5.8 kg
Dimensions (width x height x depth) 435 x 99.5 x 380 mm
Operating temperature 5°C to 40°C
Operating humidity Less than 80% (no condensation)
TV format PAL-I
Recording
Recording format Video Recording format (DVD-RW only),
Video format (DVD-RW, DVD-R)
Recordable discs DVD-ReWritable, DVD-Recordable
Video recording format
Sampling frequency
Compression format
13.5 MHz
MPEG
Audio recording format
Sampling frequency
Compression format
48 kHz
Dolby Digital
Tuner
Receivable channels
IRA-E69
Input/Output
Front Panel : (AV3)
Video input
Input level
One RCA connector
1 Vp-p (75 Ω)
S-Video input
Input level
One Mini DIN 4-pin jack
Y (Iuminance) 1 Vp-p (75 Ω)
C (colour) 300 mVp-p (75 Ω)
Audio input
Input level
Two RCA connectors
2 Vrms (input impedance: more than 10 kΩ)
Rear Panel
VHF/UHF antenna input/output terminal VHF/UHF set 75 Ω
Audio input /output Two 21-pin scart sockets (AV1, AV2)
Video input /output
Input /output level
Two 21-pin scart sockets (AV1, AV2)
1 Vp-p (75 Ω) each
S-Video output
Input /output level
One Mini DIN 4-pin jacks
Y (Iuminance) 1 Vp-p (75 Ω)
C (colour) 300 mVp-p (75 Ω)
Audio output
Output level
Two RCA connectors
2 Vrms (output impedance: 680 Ω)
Digital audio output
Output level
One Coaxial pin jack
500 mVp-p (75 Ω)
E439BBD_EN.book Page 99 Wednesday, May 31, 2006 4:01 PM
