eManager
Client PC
2-14 Strata CIX Voice Mail Programming 01/07
Client PC
eManager can be loaded on a client PC with network access to the voice mail application on the
Stratagy ES MAS. Minimum requirements for the client PC are:
• Windows 2000 Pro SP4, Windows XP Pro SP1
• 512MB RAM
• Pentium 400 MHz processor
• 1.6GB of free hard disk storage
• CD-ROM drive
• 38.4 Kbps baud modem (optional for remote maintenance through telephone network)
• 3.5” 1.44MB floppy disk drive
• SVGA card and color monitor
• mouse
• keyboard
• 10BaseT Network Interface Card (optional for remote connection through a Local Area
Network (LAN)/Wide Area Network (WAN))
There is a separate installation package (CD-ROM) provided to the client for installing the Dongle
driver. A preprogrammed USB RainBow SuperPro Dongle is used to access the eManager at a
client PC via IE Browser (not at the eManager Server).
How to Prepare the Client PC
1. Install the Rainbox Technologies, Inc. Sentinel Driver.
2. Install the MLA.dll by copying the file to the target PC (System32 folder recommended).
3. Register the MLA.dll by clicking Start >
Run and browsing for the regsvr32 file
(shown right).
4. Click OK.
Load Voice Mail Application
Software on Client PC
1. Uninstall StrataCIXAdmin.
1. Insert the CD-ROM Disk into the PC
drive. The Software Menu displays.
2. Select Stratagy ES Administration. The Welcome screen displays.
3. Accept the defaults on the following screens by clicking Next.
4. When the installation is complete, click Finish.
5. Restart the Stratagy ES Server.
Run eManager from Network (Client) PC
! Type IE//http://<PC Name>/eManager (example: http://WEBFOOT/eManager) and press
<Enter>. The Welcome screen displays.
