Toshiba TECRA A9 Series Maintenance Manual

4 Replacement Procedures 4.5 HDD
NOTE: The following steps describe how to disassemble the HDD assembly, however, do
not disassemble if the HDD is working properly.
5. Place the HDD assembly on a flat surface, and remove the following screws.
• M3×4C FLAT HEAD screw ×4
6. Separate the HDD and HDD Holder.
CAUTION: Do not apply pressure to the center of the HDD assembly. It may damage
the HDD assembly. Hold the HDD assembly by its corners.
M3×4C FLAT HEAD
HDD
HDD Holder
M3×4C FLAT HEAD
Figure 4-6 Separating the HDD and HDD holder
4-14 [CONFIDENTIAL] TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633)

Toshiba TECRA A9 Series Specifications

General

Processor	Intel Core 2 Duo
Display	15.4-inch
Display Resolution	1280 x 800 pixels
RAM	Up to 4 GB
Operating System	Windows Vista
Optical Drive	DVD-RW
Wireless	802.11a/g/n
Ports	USB 2.0, VGA, Ethernet, Headphone
