4.5 HDD 4 Replacement Procedures
TECRA A9/TECRA S5/TECRA P5/Satellite Pro S200 Maintenance Manual (960-633) [CONFIDENTIAL] 4-15
Installing the HDD
To install the HDD, follow the steps below and refer to Figure 4-4 to 4-6.
CAUTION: Do not hold the HDD by its top and bottom flat surfaces. It may damage the
HDD.
1. Install the HDD to the HDD Holder and secure them with the following screws.
• M3×4C FLAT HEAD screw ×4
CAUTION: Do not apply pressure to the center of the HDD assembly. It may damage
the HDD assembly. Hold the HDD assembly by its corners.
2. Set the connector of the HDD cable upward and connect the HDD assembly to the
connector of the HDD cable. Lay the HDD assembly down into the slot.
3. Install the HDD cover and secure it with the following screws.
• M2.5×6B FLAT HEAD screw ×2
