Toshiba TOSVERT VF-nC3E - Terminal Function Selection; Changing Control Logic Switching; Keeping an Input Terminal Function Always Active (ON); Sink;Source Switching

E6582233
F-7
6
6.3 Terminal function selection
6.3.1 Changing control logic switching
 : Sink/source switching
 Function
Logic input terminal sink logic (minus common)/source logic (plus common) and using an external
power supply are switched.
[Parameter setting]
Title Function Ad
j
ustment ran
g
e Default settin
g

Sink/source switching
0: Sink(Internal power supply),
100: Source,
200: Sink(External power supply)
1-99, 101-199, 201-255: invalid
0
★ After setting  switching, the check alarms (, , ) are displayed, reset panel,
external signal, or power.
Refer to pages B-10 and B-11 regarding sink/source logic connections.
6.3.2 Keeping an input terminal function always active (ON)
 : Always active function selection 1
 : Always active function selection 2
 Function
This parameter specifies an input terminal function that is always to be kept active (ON).
[Parameter setting]
Title Function Ad
j
ustment ran
g
e Default settin
g
 Always active function selection 1 0-153 (Refer to section 10.5) 0 (No function)

Always active function selection 2 0-153 (Refer to section 10.5) 6 (ST)
