E6582233
F-56
6
6.18.11 Cumulative operation time alarm setting
: Cumulative operation time alarm setting
Function
This parameter allows you to set the inverter so that it will put out an alarm signal after a lapse of the
cumulative operation time set with .
* "0.1" displayed on the monitor refers to 10 hours, and therefore "1" denotes 100 hours.
Ex.: 38.5 displayed on the monitor = 3850 (hours)
[Parameter setting]
Title Function Ad
ustment ran
e Default settin
Cumulative operation time
alarm settin
0.0-999.0 610.0
■ Setting of output signal
Ex.: When assigning the cumulative operation alarm signal output function to the OUT terminal
Title Function Ad
ustment ran
e Settin
Output terminal selection
1A
OUT
0-255 56: COT (Cumulative operation time alarm)
Setting value 57 is reverse signal.
6.18.12 Undervoltage trip
: Undervoltage trip/alarm selection
Function
This parameter is used for selecting the control mode when an undervoltage is detected. Trip
information is displayed as "".
=: The inverter is stopped. However, it is not tripped (Failure signal FL not activated).
The inverter is stopped when the voltage does not exceed 64 % or less of its rating.
=: Inverter is stopped. It is also tripped (Failure signal FL activated), only after detection of a voltage
not exceeding 64% or less of its rating.
=: Inverter is stopped. However, it is not tripped (Failure signal FL not activated). The inverter stop
(Failure signal FL not activated.), only after detection of a voltage not exceeding 50% of its rating.
Be sure to connect the input AC reactor specified in section 9.4.
[Parameter setting]
Title Function Ad
ustment ran
e Default settin
Undervoltage trip/alarm
selection
0: Alarm only (detection level 64% or less)
1: Tripping (detection level 64% or less)
2: Alarm only (detection level 50% or less,
input AC reactor required
0
