Toshiba TOSVERT VF-nC3E - Extended Parameters

E6582233
J-4
10
10.3 Extended parameters
 Input/output parameters 1
Ti tle
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F100 0100 Low-speed signal
output frequency
Hz 0.1/0.01 0.0- 0.0 6.1.1

F101 0101 Speed reach
setting frequency
Hz 0.1/0.01 0.0- 0.0 6.1.3

F102 0102 Speed reach
detection band
Hz 0.1/0.01 0.0- 2.5 6.1.2
6.1.3

F105 0105 Priority selection
(Both F and R are
ON)
- -
0: Reverse
1: Slowdown Stop
1 6.2.1

F108 0108 Always active
function selection 1
-
-
0-153 0 (No
functi
on)
6.3.2

F109 0109 Analog/logic input
Selection
(VI terminal)
- -
0: Voltage signal input (0-10V)
1: Current signal input (4-20mA)
2: Logic input
3: Voltage signal input (0-5V)
0 6.2.2
6.3.3
6.6.2
7.2.1
7.3

F110 0110 Always active
function selection 2
- - 0-153 6
(ST)
6.3.2

F111 0111 Input terminal
selection 1A (F)
- - 0-201 2
(F)
6.3.3
6.6.1
7.2.1

F112 0112 Input terminal
selection 2A (R)
- - 0-201 4
(R)

F113 0113 Input terminal
selection 3A (S1)
- - 0-201 10
(SS1)

F114 0114 Input terminal
selection 4A (S2)
- - 0-201 12
(SS2)

F115 0115 Input terminal
selection 5 (VI)
- - 8-55 14
(SS3)

F127 0127 Sink/source
switching
- - 0: Sink(Internal power supply),
100: Source,
200: Sink(External power supply)
1-99, 101-199, 201-255: invalid
0 6.3.1

F130 0130 Output terminal
selection 1A
(OUT)
- - 0-255 4
(LOW
)
6.3.4
7.2.2

F132 0132 Output terminal
selection 2 (FL)
- - 0-255 10
(FL)

F137 0137 Output terminal
selection 1B
(OUT)
- - 0-255 255
(alwa
ys
ON)

F139 0139 Output terminal
logic selection
(OUT)
- - 0:  and 
1: or 
0

F144 0144 Factory specific
coefficient 1A
- - - - * 1
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
