Toshiba TOSVERT VF-nC3E - Page 212

E6582233
J-5
10
Title
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F151 0151 Input terminal
selection 1B (F)
- - 0-201 0 6.3.3
6.6.1

F152 0152 Input terminal
selection 2B (R)
- - 0-201 0 7.2.1

F153 0153 Input terminal
selection 3B (S1)
- - 0-201 0

F154 0154 Input terminal
selection 4B (S2)
- - 0-201 0

F155 0155 Input terminal
selection 1C (F)
- - 0-201 0

F156 0156 Input terminal
selection 2C (R)
- - 0-201 0
 Basic parameter 2
Ti
Tle
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference

F170 0170 Base frequency 2 Hz 0.1/0.01 20.0-400.0 50 6.4.1

F171 0171 Base frequency
voltage 2
V 1/0.1 50-660 400

F172 0172 Torque boost
value 2
% 0.1/0.1 0.0-30.0 * 1

F173 0173 Motor electronic-
thermal protection
level 2
%
(A)
1/1 10-100 100 3.4
6.4.1
6.18.1

F185 0185 Stall prevention
level 2
%
(A)
1/1 10-199,
200 (disabled)
150 6.4.1
6.18.2

F190 0190 V/f 5-point setting
VF1 frequency
Hz 0.1/0.01 0.0-fh 0.0 5.11
6.5

F191 0191 V/f 5-point setting
VF1 voltage
% 0.1/0.01 0.0-125.0 0.0

F192 0192 V/f 5-point setting
VF2 frequency
Hz 0.1/0.01 0.0-fh 0.0

F193 0193 V/f 5-point setting
VF2 voltage
% 0.1/0.01 0.0-125.0 0.0

F194 0194 V/f 5-point setting
VF3 frequency
Hz 0.1/0.01 0.0-fh 0.0

F195 0195 V/f 5-point setting
VF3 voltage
% 0.1/0.01 0.0-125.0 0.0

F196 0196 V/f 5-point setting
VF4 frequency
Hz 0.1/0.01 0.0-fh 0.0

F197 0197 V/f 5-point setting
VF4 voltage
% 0.1/0.01 0.0-125.0 0.0

F198 0198 V/f 5-point setting
VF5 frequency
Hz 0.1/0.01 0.0-fh 0.0

F199 0199 V/f 5-point setting
VF5 voltage
% 0.1/0.01 0.0-125.0 0.0
*1: Default setting values vary depending on the capacity. Refer to section 10.4.
