E6582233
E-11
5
[Programmed value]
:
Terminal board VI
A frequency command is set by means of external signals (VI terminal: 0 - 5/
0 - 10 Vdc, or 0
(
4
)
-20 mAdc
)
.
:
Setting dial 1
Frequencies are set by rotating the setting dial on the inverter. Press the center
of the settin
g
dial to save the frequenc
y
settin
g
value.
:
Setting dial 2
Frequencies are set by rotating the setting dial on the inverter. Like the position
of notches in a volume knob, the frequency setting value at the position of the
notch is saved.
:
RS485
communication
Frequencies are set by commands from an external control unit.
(
Refer to section 6.21
)
:
UP/DOWN frequency
Frequencies are set by up/down commands from a terminal.
(
Refer to section 6.6.3
)
☆ No matter what value the command mode selection  and the frequency setting mode selection
 are set to the control input terminal functions described below are always in operative state.
 Reset terminal (valid only for tripping if set for programmable input terminal function)
 Standby terminal (when programmed by programmable input terminal functions).
 External input tripping stop terminal command (when so set using the programmable input terminal
function)
 Coast stop command terminal (if set for programmable input terminal function)
☆ To make changes in the command mode selection  and the frequency setting mode selection 1
, first stop the inverter temporarily.
(Can be changed while in operation when  is set to .)
☆ Priority commands from communications or terminal blocks are given priority over .
 Preset-speed operation
: Set to  (Terminal board).
: Valid in all setting values.
 Input terminal settings
Assign the following functions to the input terminal to allow switching of the frequency command by turning
the terminal ON/OFF.
Input terminal function ON OFF
48 Forced local from communication
Enabled during communication
Local (Setting of , )
Communication
106
Frequency setting mode terminal
board VI
Terminal board (VI) enabled setting of 
Each of the following numbers (49, 107) are reverse signals.
