Toshiba TOSVERT VF-nC3E User Manual

E6582233
B-1
2 2
2. Connection
Warning
Disassembly
prohibited
 Never disassemble, modify or repair.
This can result in electric shock, fire and injury. Call your Toshiba distributor for repairs.
Prohibited
 Don't stick your fingers into openings such as cable wiring hole and cooling fan covers.
This can result in electric shock or other injury.
 Don't place or insert any kind of object into the inverter (electrical wire cuttings, rods, wires). This can
result in electric shock or fire.
 Do not allow water or any other fluid to come in contact with the inverter.
That ma
y
result in electric shock or fire.
Caution
Prohibited
 When transporting or carrying, do not hold by the front panel covers.
The covers may come off and the unit will drop out resulting in injury.
2.1 Cautions on wiring
Warning
Prohibited
 Never remove the terminal cover when power is on or open door if enclosed in a cabinet.
The unit contains many high voltage parts and contact with them will result in electric shock.
Mandatory
action
 Turn power on only after attaching the front cover or closing door if enclosed in a cabinet.
If power is turned on without the terminal cover attached or closing door if enclosed in a cabinet. This
can result in electric shock or other injury.
 Electrical construction work must be done by a qualified expert.
Connection of input power by someone who does not have that expert knowledge may result in fire or
electric shock.
 Connect output terminals (motor side) correctly.
If the phase sequence is incorrect, the motor will operate in reverse and that may result in injury.
 Wiring must be done after installation.
If wiring is done prior to installation that may result in injury or electric shock.
 The following steps must be performed before wiring.
(1) Shut off all input power.
(2) Wait at least 15 minutes and check to make sure that the charge lamp is no longer lit.
If these steps are not properly performed, the wiring will cause electric shock.
 Tighten the screws on the terminal board to specified torque.
If the screws are not ti
g
htened to the specified torque, it ma
y
lead to fire.
