E6582233
J-6
10
Frequency parameters
Ti
tle
Communicati
on No.
Function Unit
Minimum
setting unit
Panel/Comm
unication
Adjustment range
Default
setting
User
setting
Reference
F201 0201 VI input point 1
setting
% 1/1 0-100 0 6.6.2
7.3
F202 0202 VI input point 1
frequency
Hz 0.1/0.01 0.0-400.0 0.0
F203 0203 VI input point 2
setting
% 1/1 0-100 100
F204 0204 VI input point 2
frequency
Hz 0.1/0.01 0.0-400.0 50
F209 0209 Analog input filter ms 1/1 4-1000
64
F240 0240 Starting frequency
Hz
0.1/0.01 0.1-10.0 0.5 6.7.1
F241 0241 Operation starting
frequency
Hz
0.1/0.01 0.0- 0.0 6.7.2
F242 0242 Operation starting
frequency
hysteresis
Hz
0.1/0.01 0.0- 0.0
F249 0249 Factory specific
coefficient 2A
- - - - * 1
F250 0250 DC braking
starting frequency
Hz 0.1/0.01 0.0- 0.0 6.8
F251 0251 DC braking
current
%(A) 1/1 0-100 50
F252 0252 DC braking time s 0.1/0.1 0.0-25.5 1.0
F256 0256 Time limit for
lower-limit
frequency
operation
s
0.1/0.1 0: Disabled
0.1-600.0
0.0 6.9
F264 0264 External logic
input - UP
response time
s 0.1/0.1 0.0-10.0 0.1 6.6.3
F265 0265 External logic
input - UP
frequency steps
Hz 0.1/0.01 0.0- 0.1
F266 0266 External logic
input - DOWN
response time
s 0.1/0.1 0.0-10.0 0.1
F267 0267 External logic
input - DOWN
frequency steps
Hz 0.1/0.01 0.0- 0.1
F268 0268 Initial value of
UP/DOWN
frequency
Hz
0.1/0.01
0.0
F269 0269 Change of the
initial value of
UP/DOWN
frequency
- - 0: Not changed
1: Setting of changed when
power is turned off
1
F270 0270 Jump frequency Hz 0.1/0.01 0.0- 0.0 6.10
F271 0271 Jumping width Hz 0.1/0.01 0.0-30.0 0.0
F287 0287 Preset-speed
frequency 8
Hz 0.1/0.01
0.0 3.5
6.11
F288 0288 Preset-speed
frequency 9
Hz 0.1/0.01
0.0
F289 0289 Preset-speed
frequency 10
Hz 0.1/0.01
0.0
F290 0290 Preset-speed
frequency 11
Hz 0.1/0.01
0.0
F291 0291 Preset-speed
frequency 12
Hz 0.1/0.01
0.0
*1: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
